Okta Cross App Access MCP - Node Example

A proof-of-concept demonstrating how a Model Context Protocol (MCP) can leverage the Identity Assertion Authorization Grant specification to enable secure and interoperable authorization of MCP clients within enterprise environments, using existing identity infrastructure.

Table of Contents

• Quickstart & Dev Setup
• Common Issues
• Troubleshooting
• Dev Tips

Quickstart & Dev Setup

• Run Locally in VS Code (Recommended):

  • Pre-requisites:
    • Docker Desktop (required for local containers)
    • VS Code (required for Dev Containers)
    • Dev Containers VSCode Extension

• GitHub Codespaces (Alternative):

  • Start a GitHub Codespace from the GitHub UI ("Code" → "Create codespace on main").
  • After the Codespace is running, connect to it using your local VS Code client via SSH:
    • In VS Code, open the Command Palette (Cmd+Shift+P on Mac, Ctrl+Shift+P on Windows/Linux)
    • Search for and select "Codespaces: Connect to Codespace via SSH"
    • Choose your running Codespace
  • This allows you to access local ports from your VS Code client as if running locally.

1. Clone and Open in VS Code

Note: If you are using GitHub Codespaces, you can skip this step as the repository will be automatically cloned for you.

git clone https://github.com/oktadev/okta-cross-app-access-mcp.git
cd okta-cross-app-access-mcp

• Open VS Code Command Palette and run "Dev Containers: Open Folder in Container". To open Command Palette, select View → Command Palette..., MacOS keyboard shortcut Cmd+Shift+P, or Windows keyboard shortcut Ctrl+Shift+P.

2. Configure Environment

yarn setup:env

Note: The yarn setup:env command copies template .env.default files to .env so you can fill in your credentials.

Edit the following files to fill in required values:

• packages/authorization-server/.env.agent
• packages/authorization-server/.env.todo
• packages/agent0/.env

Required fields:

File	Variable Name	Values
packages/authorization-server/.env.todo	CUSTOMER1_EMAIL_DOMAIN	tables.fake
	CUSTOMER1_AUTH_ISSUER	https://{orgDomain}.oktapreview.com
	CUSTOMER1_CLIENT_ID	<OIDC client id at IdP>
	CUSTOMER1_CLIENT_SECRET	<OIDC client secret at IdP>
packages/authorization-server/.env.agent	CUSTOMER1_EMAIL_DOMAIN	tables.fake
	CUSTOMER1_AUTH_ISSUER	https://{orgDomain}.oktapreview.com
	CUSTOMER1_CLIENT_ID	<OIDC client id at IdP>
	CUSTOMER1_CLIENT_SECRET	<OIDC client secret at IdP>
packages/agent0/.env	AWS_ACCESS_KEY_ID	<your AWS access key id>
	AWS_SECRET_ACCESS_KEY	<your AWS secret access key>

How to retrieve these values:

• These values are provided by your Identity Provider (IdP) when you register your OIDC application.
• For AWS credentials, to know how to generate AWS Credentials - Follow this steps
• Typically, you can find IdP values in your IdP's admin console or developer portal under the application/client settings.
• For example, in Okta, Azure AD, Auth0, or similar providers, look for the "Issuer URL" and "Client ID" fields.
• If unsure, consult your IdP or AWS documentation or administrator for guidance.

3. Install Dependencies & Seed the Database

yarn bootstrap

Note: The yarn bootstrap command will also run yarn resetdb to initialize your databases. During this process, you’ll see a prompt:

Are you sure you want to reset your database? All data will be lost.

• Type y and press Enter to reset and re-seed the databases.
• This is required the first time you run the project, or whenever you want to start with clean test data.

4. Start All Services

You can start all backend and frontend services in parallel using one of the following commands:

yarn start

• This command launches all backend and frontend services in parallel, each on its own port, so you can develop and test the full system at once.
• If you prefer, you can manually open 4 terminals and run the following commands individually for more control:
  • yarn dev:agent0
  • yarn auth:agent0
  • yarn dev:todo0
  • yarn auth:todo0

Open the Application UIs

To access the application interfaces, open your browser and navigate to:

• http://localhost:3001/ (Todo0)
• http://localhost:3000/ (Agent0)

5. Verify Your Setup

What to do if a test fails

• If an operation does not work as expected (e.g., you cannot log in, create, or edit items), check the terminal output for errors.
• Common issues include misconfigured .env files, missing database migrations, or services not running.
• Review the "Common Issues" and "Troubleshooting" sections above for guidance.

Common Issues

• App not starting? Ensure all .env files are present and filled in.
• Database errors? Try yarn resetdb to re-seed the database.
• Ports in use? Make sure no other apps are running on ports 3000, 3001, 5000, or 5001.

Troubleshooting

If you have any trouble, try re-authenticating to both applications by signing out and signing in again.

Dev Tips

Access the mysql database directly with the following:

mariadb -u root --password=avocado -P 3306

Run the following after making schema changes to a schema.prisma file

Make sure to replace the content in <>.

export AGENT_DATABASE_URL=<DB_URL>
export TODO_DATABASE_URL=<DB_URL>

License

Apache 2.0, see LICENSE.
