Forked from the original to add some extra settings, and add support for fetching data from my GNSS "War Room" project
Using some features (Displaying time, GNSS data) requires connecting to WiFi.
Connect the WOPR via USB, and open the WOPR_Display_V2 folder in the arduino IDE. Make sure "UM TinyS3" is selected as the board, and is detected. Modify secret.h to have the correct SSID and password.
(Note: may not work with QUB wifi as it usually wants a username too, I used my hotspot in the demo just to be safe)
If using for GNSS data, you'll need to modify the API URL currently hardcoded in the .ino file from gnss.mck.is
Finally, upload the code to the WOPR. (ctrl+U or the upload button in the IDE)
Button 1 (right button) in menu to go through list of modes
Button 2 (left button) to select mode
When in a mode, button 1 will exit to the menu
In settings mode, button 1 switches which setting you are on, button 2 changes the current settings value
Hold Button 1 to save/exit settings. Display will show "saving..." when triggered.
